Polyester forming mesh series

Polyester molding network according to the weaving series dicision, can be divided into four mechanized four

mechanized single-layer networkive kinds of single - layer network , eight kinds of single-layer network ,sixteen

in two and a half and three layer network series.

four single layer fabric is suitable for making culture paper ,printing paper , packaging paper
five single layer fabricuitable for making toilet paper ,cultural paper ,packaging paper.eight single layer fabric is suitable for gram weight larger bagpaper ,kraft paper, cardboard , corrugated paper ,liner board paper.
seven double layer is suitable for quality printing paper , plastic sheet printing paper , tissue,paper and paperboard facpulp,pulp and other.
eitght harness ,sixteen fully two layer and three layer fabric is suitable for semi high speed paper machine , teproduction of various types of paper.

Technical parameters of polyester forming net

Weaving serious and types	Net ID	Filament diameter mm		Density/root mm		Tensile strength N/cm		Thickness mm	Air permeability	Force-Elongation (in 50N/cm)
		Warp	Weft	Warp	Weft	surface	joint
4 heddle monolayer forming net	27254	0.20	0.25	30	22	≥600	≥400	0.49	8000	0.60%
	27274	0.20	0.27	30	21.5	≥600	≥400	0.51	7800	0.60%
	31204	0.18	0.20	35	28	≥600	≥380	0.43	7500	0.68%
	31204-1	0.18	0.20	35	30	≥600	≥380	0.43	7000	0.68%
5 heddle monolayer forming net	30205	0.17	0.20	32	28.5	≥600	≥350	0.41	7100	0.60%
	31215	0.20	0.21	35	32	≥600	≥400	0.48	7000	0.60%
	27255	0.20	0.25	30	22	≥600	≥400	0.50	8000	0.60%
8 heddle monolayer forming net	25358	0.22	0.35	28	19.5	≥700	≥500	0.85	9000	0.65%
	25388	0.22	0.38	29.5	19	≥700	≥500	0.87	8500	0.65%
	27358	0.22	0.35	29	20	≥700	≥500	0.85	8500	0.65%
	27388	0.22	0.38	31.5	19	≥700	≥500	0.87	8000	0.65%
7 shed double layer forming fabric	56177	0.17	0.17/0.22	60	48	≥800	≥600	0.635	5200	0.60%
			0.20(t66)
	57177	0.17	0.17/0.22	65.7	49.6	≥800	≥600	0.635	4550	0.60%
			0.22(t66)
8 shed double layer forming fab	56188	0.17	0.18/0.20	61.3	51.2	≥850	≥600	0.65	5700	0.60%
			0.20(t66)
	60188	0.18	0.19/0.20	66	49	≥900	≥650	0.68	4750	0.60%
			0.20(t66)
	62188	0.15	0.16/0.19	70.5	50.5	≥900	≥650	0.60	6200	0.60%
			0.19(t66)

Eight heddle,heddle two layer sixteen and layer three nerwork paremeters of semi

weaving series and types	Model	Filament diameter mm		density		Air perneability
weaving series and types	Model	Warp	weft(on the weft insertion/under)	warp	weft	Air perneability
2 and a half forming netr	2B3316-380	0.28	0.20, 0.27/0.45, 0.40	37-38	40-41	6000
	2B3316-450	0.26	0.20, 0.28/0.45, 0.45	40.5-41.5	34.5-35.5	7080
	2B5616-350	0.17	0.13, 0.20/0.35, 0.35	62.5-63.5	51.5-52.5	5500
	2B4216-435	0.22	0.15, 0.25/0.40, 0.40	47-48	42-43	6700
	2B5616-410	0.17	0.13, 0.20/0.35 , 0.35	62.5-63.5	47.5-48.5	6500
	2B5608-375	0.17	0.13, 0.20/0.25, 0.25	61-62	48-49	5940
	2B6016-350	0.17	0.13, 0.17/0.20, 0.20	65-66	57-58	5500
	2B6016-410	0.17	0.13, 0.20/0.35, 0.35	65-66	49-50	6500
3 forming net	3WB4216-400	0.22/0.22	0.18, 0.18, 0.17/0.40, 0.40	48-49	42-43	6300
	3WB5616-475	0.17/0.17	0.15, 0.25, 0.18/0.35 ,0.35	61-62	55-56	7500
	3Wb5620-315	0.15/0.20	0.17, 0.17, 0.17/0.35 ,0.35	66-67	58-59	5000
